Huawei S5735-L8T4S-A-V2 Switch

Huawei S5735-L8T4S-A-V2 Switch

Rs.150,000.00 PKR
Rs.150,000.00 PKR Rs.160,000.00 PKR
Shipping calculated at checkout.

Low stock! Only 5 left
Up to 6% off

Overview

The Huawei CloudEngine S5735-L8T4S-A-V2 is a compact gigabit access switch built for enterprise campus networks. It offers 8 x 10/100/1000BASE-T ports and 4 x GE SFP ports with a built-in AC power supply, delivering 18 Mpps forwarding performance and 24 Gbps switching capacity. Designed for flexible Ethernet networking, Layer 3 routing, and robust security control, it's well-suited for access-layer deployment in healthcare, retail, mining, and enterprise environments.

Specifications

Huawei CloudEngine S5735-L8T4S-A-V2

Product Specification Sheet

Model Information

Item Specification
Model CloudEngine S5735-L8T4S-A-V2
Description 8 x 10/100/1000BASE-T ports, 4 x GE SFP ports, built-in AC power

Performance

Item Specification
Forwarding performance 18 Mpps
Switching capacity 24 Gbps (device) / 520 Gbps (system)

Physical Specifications

Item Specification
Dimensions (H x W x D) 43.6 mm x 250 mm x 180 mm
Chassis height 1 U
Chassis weight (with packaging) 2.22 kg
Fixed GE ports 8
GE SFP ports 4
10GE ports NA

Management Ports

Item Specification
Console port (RJ45) Supported
USB port NA

Processor / Memory

Item Specification
CPU frequency 1.1 GHz
CPU cores 2
Memory (DRAM) 2 GB

Power Supply

Item Specification
Power supply type Built-in AC power supply
Rated voltage range 100 V AC to 240 V AC, 50/60 Hz
Maximum voltage range 90 V AC to 290 V AC, 45 Hz to 65 Hz
Maximum input current 0.8 A
Maximum power consumption 21.52 W
Typical power consumption 15.95 W
Static power consumption 10.52 W

Heat Dissipation

Item Specification
Heat dissipation mode Air-cooled, intelligent speed adjustment
Number of fan modules 1
Airflow Intake from left and front, exhaust from right
Max heat dissipation 73.43 BTU/hour

Environmental Parameters

Item Specification
Long-term operating temperature -5°C to +50°C (0–1800 m altitude; -1°C per 220 m above)
Storage temperature -40°C to +70°C
Relative humidity 5%–95% (non-condensing)
Operating altitude Up to 5000 m
Noise (sound power) 44.5 dB(A)
Noise (sound pressure) 32.5 dB(A)
Surge protection (power port) Differential mode ±6 kV / Common mode ±6 kV

Reliability

Item Specification
MTBF 75.32 years
MTTR 2 hours
Availability > 0.99999

Certifications

Item Specification
Certifications EMC certification, Safety certification, Manufacturing certification

Layer 2/3 & Routing Features

Item Specification
Loop protection STP/RSTP/MSTP, ERPS (G.8032), Smart Link
Routing protocols RIP, OSPFv2/v3, VRRPv4/v6, static routing, policy-based routing
Routing table capacity Up to 4096 FIBv4 entries / 1024 FIBv6 entries
VLAN 4K VLANs, Voice VLAN, MUX VLAN, VLAN Stacking/Mapping

Security Features

Item Specification
Authentication 802.1X, Portal authentication, MAC address authentication
DHCP protection DHCP snooping, DHCP relay/server/client
Attack defense DoS attack defense, ARP attack defense, ICMP attack defense
ACLs 2K rules per IPv4 ACL, 2K rules per IPv6 ACL

Management & Maintenance

Item Specification
Protocols SNMPv1/v2/v3, CLI, SSHv2.0, HTTPS, NETCONF/YANG
Monitoring Telemetry, sFlow, NQA, RMON
Stacking iStack (80 Gbps stack bandwidth)

Source: Huawei official CloudEngine S5735-L-V2 Series Datasheet (PDF)
